Rinnai R3655 – High Wind Vert Cowl Protct Kit

Product Details: Rinnai R3655

Rinnai R3655 – High Wind Vert Cowl Protct Kit, part of the Ember Series range. Meet the Rinnai Ember, Compact Series Fireplace. The small gas fire. Genuine Rinnai New Zealand product, brand new, supplied through Rinnai NZ’s trade channel.

Rinnai R3655 — Specifications

Product Overview
Product	High Wind Vert Cowl Protct Kit
Rinnai Part Number	R3655
Product Range	Ember Series
Category	Home Heating > Fires & Fireplaces > Flueing Components
Brand	Rinnai
Technical Specifications
Gas type	Available for Natural Gas or LPG, specify at the time of purchase
Convection fan	120 V AC 50 Hz 2-speed centrifugal blower. Heat is distributed from the top of the appliance.
Data plate	Located on the lower RHS of the base panel, in front of the gas control.
Gas connection	Brass ½ ” BSPT male fitting. The gas supply terminates inside the heater, lower RHS of the appliance.
Ignition	230-240 V AC 50 HZ high voltage electronic spark generation unit.
Noise level	37-45 dB(A)
Flueing – masonry	Colinear flexi flue, air intake Ø 75 mm, exhaust Ø 100 mm. Appliance must be installed with a Rinnai Ember flue system.; Refer below comment regarding the DV high wind vertical cowl protection kit.
Flueing – mock chimney	Colinear (air intake Ø75 mm, exhaust Ø100 mm) to coaxial direct vent flueing (inner Ø100 mm, outer Ø170 mm). Appliance must be installed with a Rinnai Ember flue system.; N.B; : For windy areas such as Wellington, coastal properties, and elevated properties on hills we recommend an additional flue component call the DV high wind vertical cowl protection kit (R3655). It is designed to wrap around the flue cowl to reduce wind entering the flue and causing flame disturbances. Refer to the installation instructions in the ‘Downloads’ tab for more information.
Power consumption	High 110 W; Standby < 1 W; The Ember has a 1.5 m power cord with a 3-pin plug supplied. The power cord passes through a slot in the back right hand corner of the appliance.
Safety devices	Flame failure sensing system, pressure relief, overheat safety switch, air temperature sensor, thermal fuse, overcurrent fuse, and spark detector.
Temperature control	Operated using a basic infra-red remote, or for more features such as timers and thermostatic control, by using a Wi-Fi module (purchased separately) and using the Rinnai Wi-Fi fireplace controller app.
Weights	Ember 600 – 51 kg; Ember 700 – 55 kg
General clearances	The minimum clearances listed below are measured from the edge of the outer glass.; Above – 400 mm; Sides – 400 mm (includes side walls); In front – 1000 mm
Dimensions	These are the unit dimensions only, not the framing/cavity dimensions; Ember 600: A-640 mm, B-644 mm, C-618 mm, D-580 mm; Ember 700: A-740 mm, B-644 mm, C-618 mm, D-680 mm; Viewable glass dimensions; – Ember 600: 535 (w) x 500 (h) mm; – Ember 700: 638 (w) x 500 (h) mm
Compliance	Energy Safety Supplier Declaration of Compliance: Declaration number – 1810620176
Market release	June 2017

Documents & Downloads

• 📄 Gas fireplace & home heating brochure
• 📄 Ember Series ordering guide
• 📄 Gas fireplace spec guide
• 📄 Ember operation guide
• 📄 Ember installation guide
• 📄 Ember product technical statement
• 📄 DV high wind vertical cowl protection kit (R3655) installation
• 📄 Ember mock chimney zero clearance frame installation
• 📄 Ember mock chimney horizontal flue kit installation
• 📄 Ember 600 burn media sheet on unit
