Haier AD105S2SM7FA – Indoor (low profile) (Indoor Unit Only)
Image is for illustration only. Please go by the model number (SKU: AD105S2SM7FA).
-19%Roll over image to zoom in
$1,209.99$1,489.99 (-19%)
Price Match*
Price Match*
💬
Custom Quote Required
Direct checkout is temporarily disabled for this item. Please use the Request Quote / Enquiry button below to get accurate pricing and availability.
COOLING
10.50 kW
HEATING
12.00 kW
Genuine Haier AD105S2SM7FA – Indoor (low profile). Brand new, 5-year Haier warranty, NZ-wide delivery from NZ Depot.
⚠️ This is the INDOOR UNIT ONLY. It is not a complete heat pump and will not work on its own. It needs the matching outdoor unit.
⚠️ Important Compatibility Notice
Please double-check the required specifications with your qualified technician or installer prior to ordering. Due to the technical nature of this product, incorrect orders cannot be exchanged, replaced, or refunded. Thank you for your understanding.
Haier AD105S2SM7FA – Indoor (low profile) (Indoor Unit Only): Genuine Haier Trade Supply
You are viewing the Haier AD105S2SM7FA – Indoor (low profile) (Indoor Unit Only) (SKU: AD105S2SM7FA). This is a 100 percent genuine Haier Smart Power Low Profile Ducted Smart Power Low Profile Ducted Indoor Units component, engineered for New Zealand homes and commercial sites. Refrigerant: R32. Cooling capacity: 10.5kW. Heating capacity: 12kW.
Product Details: Haier AD105S2SM7FA
Haier AD105S2SM7FA – Indoor (low profile). Genuine Haier product, brand new with full NZ warranty support.
This listing is the INDOOR UNIT ONLY – it requires a compatible Haier outdoor unit to operate. See the complete set listing for the full system.
Key Features
- ✓ 24 Hour timer
- ✓ Auto restart
- ✓ Blue fin coils
- ✓ Condensate pump
- ✓ DRED (Demand Response) ready
- ✓ Dry mode
- ✓ Inverter controlled compressor
- ✓ MEPS approved
- ✓ Self diagnostics
- ✓ Smart Appliance
- ✓ Voice control via Google Home or Amazon Alexa
- ✓ DC inverter
- ✓ R32 Refrigerant
Haier AD105S2SM7FA — Full Specifications
| Unit Overview | |
| Cooling Capacity | 10.5 kW |
| Heating Capacity | 12 kW |
| Refrigerant | R32 |
| Brand | Haier |
| Series | Smart Power Low Profile Ducted |
| SKU | AD105S2SM7FA |
| Warranty | 5 Years |
| Accessories (included) | |
| Standard controller | Optional |
| Capacity | |
| Cooling capacity (kW) | 10.5kW |
| Heating capacity (kW) | 12kW |
| Consumption | |
| COP | 3.50 |
| EER | 3.20 |
| HSPF-RES (Hot/Average/Cold) | 3.945/3.488/3.017 |
| HSPFCOM (Hot/Average/Cold) | 3.94/3.672/3.176 |
| TCSPF-COM (Hot/Average/Cold) | 4.401/4.435/4.707 |
| TCSPF-RES (Hot/Average/Cold) | 4.124/3.82/3.918 |
| Features | |
| Refrigerant factory charge | 2.3kg |
| Installation | |
| Indoor unit model | AD105S2SM7FA |
| Indoor unit weight | 52kg |
| Outdoor unit model | 1U105S5SN5FA |
| Outdoor unit weight | 74kg |
| Pipe length maximum | 50m |
| Pipe size gas | 15.88 (⅝) |
| Pipe size liquid | 9.52 (⅜) |
| Performance | |
| Airflow | 560/485/385/360 |
| Indoor sound pressure SPL | 44/40/37/34dBA |
| Outdoor sound power SWL | 68dBA |
| Outdoor sound pressure SPL | 52dBA |
| Working temperature cooling | -20℃ to +24℃ |
| Working temperature heating | -15℃ to +50℃ |
| Power requirements | |
| Minimum circuit amps | 23MCA |
| Power phase | Single phase |
| Power supply | 1/220~240/50 |
| Supply frequency | 50Hz |
| Supply voltage | 230V |
| Product dimensions | |
| Indoor unit depth | 870mm |
| Indoor unit height | 248mm |
| Indoor unit width | 1500mm |
| Outdoor unit depth | 370mm |
| Outdoor unit height | 965mm |
| Outdoor unit width | 950mm |
| Warranty | |
| Parts and labour | 5 years |
✔ 5-Year Haier Parts & Labour Warranty — genuine Haier product, with full local warranty support. Warranty details.
Every Haier AD105S2SM7FA sold by NZ Depot is brand new in original packaging and dispatched NZ-wide. Contact NZ Depot for a quote.
Need advice or a quote? Contact NZ Depot or browse more heat pump and HVAC deals at NZ Depot.
Pro Tip: Ensure this AD105S2SM7FA matches your installation. Sourced directly from the Haier NZ supply chain for full compatibility and manufacturer warranty.
Downloads and Documents
Browse the full range of Haier Indoor Units available for NZ-wide trade and retail supply.
© 2026 NZ Depot Limited. All Rights Reserved. | 100% NZ Owned and Operated.
Additional information
| Weight | 52 kg |
|---|---|
| Dimensions | 870 × 1500 × 248 mm |
| MPN | |
| Brand | |
| Cooling Capacity (kWs) | |
| Heating Capacity (kWs) | |
| Copper Pipe (mm) | |
| Refrigerant | |
| Series | |
| Unit Type | |
| Indoor Subtype |
