Haier ABH071H5ERG - Indoor (Indoor Unit Only)
Image is for illustration only. Please go by the model number (SKU: ABH071H5ERG).
-18%Roll over image to zoom in
$979.99$1,199.99 (-18%)
Price Match*
Price Match*
💬
Custom Quote Required
Direct checkout is temporarily disabled for this item. Please use the Request Quote / Enquiry button below to get accurate pricing and availability.
COOLING
7.10 kW
HEATING
8.00 kW
Genuine Haier ABH071H5ERG - Indoor. Brand new, 5-year Haier warranty, NZ-wide delivery from NZ Depot.
⚠️ This is the INDOOR UNIT ONLY. It is not a complete heat pump and will not work on its own. It needs the matching outdoor unit.
⚠️ Important Compatibility Notice
Please double-check the required specifications with your qualified technician or installer prior to ordering. Due to the technical nature of this product, incorrect orders cannot be exchanged, replaced, or refunded. Thank you for your understanding.
Haier ABH071H5ERG - Indoor (Indoor Unit Only): Genuine Haier Trade Supply
You are viewing the Haier ABH071H5ERG - Indoor (Indoor Unit Only) (SKU: ABH071H5ERG). This is a 100 percent genuine Haier Smart Power Cassette Smart Power Cassette Indoor Units component, engineered for New Zealand homes and commercial sites. Refrigerant: R32. Cooling capacity: 7.1kW. Heating capacity: 8kW.
Product Details: Haier ABH071H5ERG
Haier ABH071H5ERG - Indoor. Genuine Haier product, brand new with full NZ warranty support.
This listing is the INDOOR UNIT ONLY - it requires a compatible Haier outdoor unit to operate. See the complete set listing for the full system.
Key Features
- ✓ 360° airflow
- ✓ Auto restart
- ✓ Auto swing-up and down
- ✓ Blue fin coils
- ✓ Concealed LED display
- ✓ Condensate pump
- ✓ Electronic expansion device
- ✓ Fresh air connection
- ✓ Infrared remote control
- ✓ Inverter controlled compressor
- ✓ MEPS approved
- ✓ Smart Appliance
- ✓ R32 Refrigerant
Haier ABH071H5ERG - Full Specifications
| Unit Overview | |
| Cooling Capacity | 7.1 kW |
| Heating Capacity | 8 kW |
| Refrigerant | R32 |
| Brand | Haier |
| Series | Smart Power Cassette |
| SKU | ABH071H5ERG |
| Warranty | 5 Years |
| Accessories (included) | |
| Standard controller | YR-HQS01 |
| Capacity | |
| Cooling capacity (kW) | 7.1kW |
| Heating capacity (kW) | 8kW |
| Consumption | |
| COP | 3.81 |
| EER | 3.43 |
| HSPF-RES (Hot/Average/Cold) | 4.330/3.927/3.448 |
| HSPFCOM (Hot/Average/Cold) | 4.326/4.078/3.679 |
| Star-Cool (Hot/Average/Cold) | 2.5/2.0/1.5 |
| Star-Heat (Hot/Average/Cold) | 2.5/2.0/2.0 |
| TCSPF-COM (Hot/Average/Cold) | 4.41/4.37/4.6 |
| TCSPF-RES (Hot/Average/Cold) | 4.140/3.762/3.797 |
| Features | |
| Compressor type | Twin rotary |
| DRED (Demand Response) ready | Optional HPRT-DRA001 |
| Motor type | DC motor |
| Refrigerant factory charge | 1.7kg |
| Standard panel | PB-950KB |
| Installation | |
| Indoor unit model | ABH071H5ERG |
| Indoor unit weight | 31kg |
| Outdoor unit model | 1U71S2SS5FA |
| Outdoor unit weight | 60kg |
| Pipe length maximum | 50m |
| Pipe size gas | 15.9mm |
| Pipe size liquid | 9.52mm |
| Performance | |
| Airflow | 445/415/375/335 |
| Indoor sound pressure SPL | 35-26dBA |
| Outdoor sound power SWL | 64dBA |
| Outdoor sound pressure SPL | 62dBA |
| Sound pressure | 47dBA |
| Working temperature cooling | -20°C to +24°C |
| Working temperature heating | -15℃ to +50℃ |
| Power requirements | |
| Minimum circuit amps | 16MCA |
| Power phase | Single phase |
| Supply frequency | 50Hz |
| Supply voltage | 220-240V |
| Product dimensions | |
| Indoor unit depth | 840mm |
| Indoor unit height | 246mm |
| Indoor unit width | 840mm |
| Net weight | 31kg |
| Outdoor unit depth | 372mm |
| Outdoor unit height | 760mm |
| Outdoor unit width | 920mm |
| Warranty | |
| Parts and labour | 5 years |
Documents & Downloads
- 📄 HAIER 2D DXF en ABH071HS5FA SET HVAC HHV 90005593A NZ AU
- 📄 HAIER 2D DWG en ABH071HS5FA SET HVAC HHV 90005592A NZ AU
✔ 5-Year Haier Parts & Labour Warranty - genuine Haier product, with full local warranty support. Warranty details.
Every Haier ABH071H5ERG sold by NZ Depot is brand new in original packaging and dispatched NZ-wide. Contact NZ Depot for a quote.
Need advice or a quote? Contact NZ Depot or browse more heat pump and HVAC deals at NZ Depot.
Pro Tip: Ensure this ABH071H5ERG matches your installation. Sourced directly from the Haier NZ supply chain for full compatibility and manufacturer warranty.
Downloads and Documents
Browse the full range of Haier Indoor Units available for NZ-wide trade and retail supply.
© 2026 NZ Depot Limited. All Rights Reserved. | 100% NZ Owned and Operated.
Additional information
| Weight | 31 kg |
|---|---|
| Dimensions | 840 × 840 × 246 mm |
| MPN | |
| Brand | |
| Cooling Capacity (kWs) | |
| Heating Capacity (kWs) | |
| Copper Pipe (mm) | |
| Refrigerant | |
| Series | |
| Unit Type | |
| Indoor Subtype |
