Danfoss Thermostat, Kp71 060L111366 | Controls
Roll over image to zoom in
$417.99$759.98 (-45%)
Price Match*
Price Match*
⚠️ Important Compatibility Notice
Please double-check the required specifications with your qualified technician or installer prior to ordering. Due to the technical nature of this product, incorrect orders cannot be exchanged, replaced, or refunded. Thank you for your understanding.
Danfoss Thermostat, Kp71: Commercial Grade Reliability
You are viewing the Danfoss Thermostat, Kp71 (060L111366). This is a genuine, high-specification Controls component designed for professional installations. Whether you are fitting out a commercial HVAC system, upgrading industrial refrigeration infrastructure, or handling a residential maintenance job, this unit delivers the engineering standard required for New Zealand conditions.
Technical Specification: Danfoss 060L111366
| General Information | |
|---|---|
| Charge Type | Adsorption |
| Model Number | 060L111366 |
| Product Group | Mechanical T/Stat |
| Type | KP71 |
| Electrical | |
| Contact Function | SPDT |
| Contact Rating AC1 | 16 A, 400 V |
| Contact Rating AC3 | 16 A, 400 V |
| Contact Rating AC15 | 10 A, 400 V |
| Contact Rating DC13 | 12 A, 220 V |
| Contact Rating LR | 112 A, 400 V |
| Electric Connection | Rubber cable gland |
| Electric Connection Size | 6-14 mm |
| Flex, Ferrules | 0.5 - 1.5 mm² |
| Flex, No Ferrules | 0.7 - 2.5 mm² |
| IP Class | IP30 |
| Rated Impulse Voltage | 4 kV |
| Recommended Fuse | 16A |
| Solid/Stranded | 0.75 - 2.5 mm² |
| Logistical Information | |
| Commodity Code | 90321080 |
| Country Of Origin | POL |
| EAN | 5702428014854 |
| Gross Weight | 0.44 kg |
| Measurements | |
| Capillary Tube Length | 78 3/4 in, 2000 mm |
| Net Weight | 0.37 kg |
| Weight | 0.37 kg |
| Pressure | |
| Diff | 3-10/2.2-9 °C |
| Diff Type | Adjustable |
| Sensors | |
| Sensor Size (Diameter x Length) | 9.5×115 mm |
| Sensor Type | Remote bulb |
| Standards | |
| Approval | BV, CCC, CE, CMIM, DNV, EAC, GL, LLC CDC EURO-TYSK, LR, LVD, PZH, RINA, RMRS, RoHS China, UKCA, c UL us UL873, CS C22.2 |
| Temperature | |
| Ambient Temperature | -40-65 °C |
| Ambient Temperature Note | 80 °C/176 °F for max 120 min |
| Ambient Temperature Range | -40-65 °C |
| Max Ambient Temperature | 65 °C |
| Max Sensor Temperature | 80 °C |
| Max Temperature | 20 °C |
| Min Ambient Temperature | -40 °C |
| Min Temperature | -5 °C |
| Temperature Range | -5-20 °C |
| Temperature Control & Settings | |
| Diff Range | -5-20 °C |
| Diff at Max Range Setting | 2.2-9.0 °C |
| Diff at Min Range Setting | 3.0-10.0 °C |
💡 Pro Tip: Ensure this 060L111366 matches your system requirements.
Need more options? Explore our complete range of professional Components Supplies available for NZ-wide delivery.
Additional information
| Weight | 0.44 kg |
|---|---|
| Dimensions | 78 mm |
| MPN | |
| Brand | |
| Copper Pipe (mm) |
