Danfoss Shut-Off Valve Sva-S 150 Steel 148B6220 | Industrial Valves
Image is for illustration only. Please go by the model number (SKU: 148B6220).
-45%Roll over image to zoom in
$4,806.99$8,739.98 (-45%)
Price Match*
Price Match*
⚠️ Important Compatibility Notice
Please double-check the required specifications with your qualified technician or installer prior to ordering. Due to the technical nature of this product, incorrect orders cannot be exchanged, replaced, or refunded. Thank you for your understanding.
Danfoss Shut-Off Valve Sva-S 150 Steel: Commercial Grade Reliability
You are viewing the Danfoss Shut-Off Valve Sva-S 150 Steel (148B6220). This is a genuine, high-specification Industrial Valves component designed for professional installations. Whether you are fitting out a commercial HVAC system, upgrading industrial refrigeration infrastructure, or handling a residential maintenance job, this unit delivers the engineering standard required for New Zealand conditions.
Technical Specification: Danfoss 148B6220
| General Information | |
|---|---|
| Equipment | Handwheel |
| Model Number | 148B6220 |
| Product Group | Stop Valves |
| Additional Info | |
| Family | SVA angle |
| Connections | |
| Inlet Connection Size | 1 in, 25.0 mm |
| Inlet Type | Butt weld |
| Outlet Connection Size | 6 in, 150.0 mm |
| Outlet Type | Butt weld |
| Kv Values | |
| Kv Value | 785.000 m³/h |
| Logistical Information | |
| Commodity Code | 84818099 |
| Country Of Origin | CHN |
| EAN | 5702428468718 |
| Gross Weight | 50 kg |
| Material | |
| Body Material | Steel |
| Connection Material | Steel |
| Measurements | |
| Net Weight | 42.91 kg |
| Pressure | |
| Max Operating Pressure | 52.0 Bar |
| Refrigerant | |
| Refrigerant | R22, R23, R32, R113, R114, R125, R134a, R152a, R170, R227ea, R236fa, R245fa, R290, R401A, R402A, R402B, R404A, R407A, R407B, R407C, R407F, R407H, R408A, R409A, R410A, R413A, R417A, R421A, R422A, R422B, R422D, R427A, R438A, R442A, R444B, R447A, R447B, R448A, R449A, R449B, R450A, R452A, R452B, R454A, R454B, R454C, R455A, R463A, R502, R503, R507A, R512A, R513A, R513B, R515A, R515B, R516A, R600, R600a, R717, R744, R1150, R1233zd(E), R1234yf, R1234ze(E), R1270, R1336mzz(Z), RE170 |
| Standards | |
| Approval | CE, EAC, LLC CDC TYSK, UKCA |
| Temperature | |
| Temperature Range | -60-150 °C |
| Valves | |
| CV Value | 910.600 gal/min |
| Direction | Angleway |
| Flow Direction | Bi-flow |
| Flow Direction Indicator | Embossed 1-way arrow |
| Fluid Group | 1 |
💡 Pro Tip: Ensure this 148B6220 matches your system requirements.
Need more options? Explore our complete range of professional Components Supplies available for NZ-wide delivery.
Additional information
| Weight | 7.784 kg |
|---|---|
| Dimensions | 396 × 107 mm |
| MPN | |
| Brand | |
| Copper Pipe (mm) | |
| Refrigerant |
