Danfoss Pressure Switch, Kp15A 060-129491 | Controls
Roll over image to zoom in
$1,704.99$3,099.98 (-45%)
Price Match*
Price Match*
⚠️ Important Compatibility Notice
Please double-check the required specifications with your qualified technician or installer prior to ordering. Due to the technical nature of this product, incorrect orders cannot be exchanged, replaced, or refunded. Thank you for your understanding.
Danfoss Pressure Switch, Kp15A: Commercial Grade Reliability
You are viewing the Danfoss Pressure Switch, Kp15A (060-129491). This is a genuine, high-specification Controls component designed for professional installations. Whether you are fitting out a commercial HVAC system, upgrading industrial refrigeration infrastructure, or handling a residential maintenance job, this unit delivers the engineering standard required for New Zealand conditions.
Technical Specification: Danfoss 060-129491
| General Information | |
|---|---|
| Product Group | Pressure Controls Mechanical |
| Reset Left Side | Auto |
| Reset Right Side | Manual Max |
| Type | KP15A |
| Compatibility | |
| Lubricants Compatibility | Oilfree applications |
| Connections | |
| Pressure Connection Size | 10 x 0.75 |
| Pressure Connection Standard | ISO 261 |
| Pressure Connection Type | M |
| Pressure Male/Female | Male |
| Electrical | |
| Contact Function | SPDT+SPST(NO) |
| Contact Rating | AC1=16 A, 400 V, AC3=16 A, 400 V, AC15=10 A, 400 V, DC13=12 W, 220 V, LR=112 A, 400 V, Terminal D: 50 VA, 400 V |
| Electric Connection | Rubber cable gland |
| Electric Connection Size | 6-14 mm |
| IP Class | IP30 |
| Features | |
| Serviceable | No |
| Pressure | |
| Diff Right Side | 4.0 Bar |
| Max Operating Pressure Left Side | 17.0 Bar |
| Max Operating Pressure Right Side | 35.0 Bar |
| Max Test Pressure Left Side | 20 Bar |
| Max Test Pressure Right Side | 35 Bar |
| Pressure Sensing Elements | Bellows |
| Refrigerant | |
| Oil Free Refrigerants | R134a, R513A, R515B |
| Refrigerant | R22, R113, R124, R134a, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R438A, R448A, R449A, R449B, R450A, R452A, R454C, R455A, R507A, R513A, R515B, R717, R1234yf, R1234yz, R1234ze(E) |
| UL Approved Refrigerants | R22, R113, R124, R134a, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R438A, R448A, R449A, R449B, R450A, R452A, R507A, R513A, R515B, R717 |
| Standards | |
| Approval | BV, CCC, CE, DNV, EAC, GL, LLC CDC EURO-TYSK, LR, LVD, PZH, RINA, RMRS, RoHS China, UKCA, c UL us UL873, CS C22.2 |
| Temperature | |
| Ambient Temperature Note | 80 °C/176 °F for max 120 min |
💡 Pro Tip: Ensure this 060-129491 matches your system requirements.
Need more options? Explore our complete range of professional Components Supplies available for NZ-wide delivery.
Additional information
| Weight | 0.536 kg |
|---|---|
| Dimensions | 190 × 90 mm |
| MPN | |
| Brand | |
| Copper Pipe (mm) | |
| Refrigerant |
