1/4 in 1/2 in

Henry Oil Filter/Drier 3/8MSAEThe function of an Oil Filter is to remove system debris from the refrigerantoil. The function of an Oil Filter Drier is to remove both system debris andmoisture from the refrigerant oil. Their purpose is to protect compressors andoil level regulators from damage.ApplicationsThe Henry Technologies S-4004 oil filter and S-4005 oil filter drier can beused in both Low and High Pressure Oil Management Systems. Models aresuitable for HCFC and HFC refrigerants along with their associated oils.The unique drying features of the S-4005 model are particularly suited forsystems using POE oil. This type of oil is more hydroscopic than mineral oil.This means that POE oil absorbs moisture at a much higher rate. Moisturein a refrigeration system can produce problems and/or harmful conditions.One S-4004 or S-4005 model can be fitted in the oil return line between theoil separator and oil reservoir, instead of fitting one oil strainer per oil levelregulator. These models will also remove more debris than traditional oilstrainers.Main FeaturesS-4005 and SH-4005 models• High flow capacity with low pressure drop• Large filter area• Micronic filtration• High level of drying• Eliminates the need to fit individual oil return line strainersTechnical SpecificationS-4005 modelAllowable operating pressure = 0 to 31 bargAllowable operating temperature = -10oC to +100o CFilter surface area = 3000 cm2Filter particle retention = 6 micronDrier = 131cm3 of XH9 desiccant SH-4005 modelSame as S-4005, except it has a higher operatingpressure.Allowable operating pressure = 0 to 45 barg
